AMD Ryzen Threadripper 9960X Workstation...

Description AMD Ryzen Threadripper 9960X Workstation Processor Tray 100-100001595 General Specifications Name AMD Ryzen™ Threadripper™ 9960X Family Ryzen Threadripper Series Ryzen Threadripper 9000 Series Form Factor Desktops Market Segment Enthusiast Desktop AMD PRO Technologies No Regional Availability Global Former Codename Shimada Peak Processor Architecture Zen 5 # of CPU Cores 24 Multithreading (SMT) Yes # of Threads 48 Max. Boost Clock Up to 5.4 GHz Base Clock 4.2 GHz L1 Cache 1920 KB L2 Cache 24 MB L3 Cache 128 MB Default TDP 350W Processor Technology for CPU Cores TSMC 4nm FinFET Processor Technology for I/O Die TSMC 6nm FinFET Package Die Count 5 Unlocked for Overclocking Yes AMD EXPO™ Memory Overclocking Technology Yes Precision Boost Overdrive Yes Curve Optimizer Voltage Offsets Yes CPU Socket sTR5 Supporting Chipsets TRX50 CPU Boost Technology Precision Boost 2 Instruction Set x86-64 Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 Thermal Solution (PIB) Not Included Max. Operating Temperature (Tjmax) 95°C *OS Support Windows 11 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit , Windows 10 – 64-Bit Edition Connectivity Native USB 3.2 Gen 2 (10Gbps) 4 Native SATA Ports 2 PCI Express® Version PCIe® 5.0 Native PCIe® Lanes (Total/Usable) 92, 88 NVMe Support Boot , RAID0 , RAID1 , RAID5 , RAID10 System Memory Type DDR5 Memory Channels 4 System Memory Subtype RDIMM System Memory Specification Up to 6400 MT/s ECC Support Yes (Default Enabled) Graphics Capabilities Graphics Model Discrete Graphics Card Required Manageability DASH Support Yes Security AMD Memory Guard Yes AMD Secure Processor Support Yes Windows Secure Boot Support Yes UEFI Secure Boot Support Yes Windows Device Guard Support Yes Guest Mode Execution (GMET) Trap Support Yes Virtualization-Based Security (VBS) Support Yes Windows Secured-Core PC Support Yes Firmware TPM Yes AMD-V (SVM) Support Yes AMD-V Nested Paging (RVI) Support Yes AMD AVIC (Interrupt Virtualization) Support Yes AMD-Vi (I/O MMU Virtualization) Support Yes Second Level Address Translation (SLAT) Supported Yes Advanced Encryption Standard New Instructions (AES-NI) Yes AMD Enhanced Virus Protection (NX bit) Yes FIPS Certification In Review Key Features Supported Technologies AMD EXPO™ Technology , AMD Ryzen™ Technologies Warranty 3 Years Note** **Prices, Specifications & Features are subject to change without notice
